- 23 HP V-Twin Kawasaki FR series engine is a commercial-grade power plant that features cast iron cylinder liners for long life, automatic compression release for easy starting and internally vented carburetor for better fuel management
- 52 in. 11-Gauge steel fabricated deck with 3 blades is durable and delivers a great cut
- Dial-operated cutting height selector eliminates pins and levers to set your exact cutting height; foot operated deck lift with 13 cutting height positions in increments ranging from 1.5 in. to 4.5 in. for a customized cut
- Twin EZT hydrostatic transaxles designed to deliver responsive, smooth, effortless control
- Commercial-style dual arm deck lift with a 4-point hanging system for superior deck stability and an even cut
- Fully welded tubular steel frame with 3 in. x 1.5 in. frame rails welded - not bolted at every joint - for extra strength and stability
- High back comfort seat, with standard armrests offers superb operator comfort
- Padded control arms isolate vibration while operating the mower
- Push button cruise control maintains a desired speed for consistent mowing
- In most shipping areas, Ariens offers white glove delivery service; zero-turn mower will be shipped to your local Ariens authorized servicing dealer for setup and inspection prior to home delivery; inspection includes operator's manual confirmation, set tire pressure, check fluid levels, test start unit and file warranty registration information
- Disclaimer in qualifying area only - if an Ariens authorized dealer is not in your shipping area, zero-turn will ship unassembled, directly to you via regular truck delivery; to confirm white glove delivery availability prior to purchasing, call 888-927-4367 option #2 then option #6
| Item Weight | 635 |
| Included | Battery(s),Engine oil |
| Maximum Reverse Speed (mph) | 3 |
| Maximum Cutting Height (in.) | 4.5 |
| Horsepower (hp) | 23 |
| Maximum Forward Speed (mph) | 7 |
| Returnable | 30-Day |
| White Glove Service | White Glove Service |
| Lawn Mower Type | Zero Turn Mower |
| Engine Torque (ft.-lb.) | 39.5 |
| Refurbished | No |
| Included with Riding Mowers | Battery(s),Engine Oil |
| Deck Type | Fabricated |
| Minimum Cutting Height (in.) | 1.5 |
| Power Type | Gas |
| Cutting Options | Bag,Mulch,Side-Discharge |
| Engine Displacement (cc) | 726 |
| Commercial / Residential | Residential |
| Recommended Oil Type | SAE 10W-30 |
| Start Type | Electric |
| Deck Material | 11 Gauge Steel |
| Mower Size | Large |
| Riding Mower Features | Adjustable Cutting Height,Hour Meter,Keyed start,Zero-Turn Capable |
| CA (CARB) Compliant | Not CARB Compliant |
| Number of Blades | 3 blades |
| Terrain Type | Flat with Obstacles |
| Fuel Tank Capacity (gallons) | 2.8 |
| Horsepower (hp)2 | 23 hp |
| Number of Deck Wheels | 3 |
| Transmission Type | Hydrostatic |
| Number of Blades2 | 3 |
| Size of Yard | 2 - 4 Acres |
| Drive Type | Rear-wheel Drive |
| Number of Cylinders | V-Twin |
| Product Weight (lb.) | 635 |
| Engine Make | Kawasaki |
| Assembly Required | Yes |
| Oil Capacity (oz.) | 64 |
| Rear Wheel Size (in.) | 18 in. |
| Assembled Height (in.) | 40.9 in |
| Front Wheel Size (in.) | 11 |
| Mower Deck Width | 52 |
| Rear Wheel Size (in.)2 | 18 |
| Cutting Width | 52 inches |
| Assembled Depth (in.) | 77.5 in |
| Assembled Width (in.) | 63.4 in |
| Turning Radius (in.) | 0 |
| Manufacturer Warranty | 3 year limited consumer warranty and 5 year limited warranty on deck shell and frame |
| Certifications and Listings | No Certifications or Listings |
